Wireless Specifications:

Supported Speed for Each Mode:IEEE 802.11b: 11 Mbps*3
IEEE 802.11g: 54 Mbps*3
IEEE 802.11n: 130 Mbps*3Wireless LAN Security:WPA/WPA2-Personal (with optional ELPAP10)

Screen Size (Projected Distance):

Screen Size (Projected Distance):60” – 100” [35.4 – 60.1 cm] 74.3” screen 44.3cm

Interactive Specifications:

Interactive Technology:Technology: Infrared
Interactive Pen Digital Pen (Easy Interactive Pen 1,2)
Fingers: Finger (1-6 fi ngers)Calibration Method:Pen: Auto / Manual (25points)
Finger: Manual (16points)

Operating Temperature:

Single Use:5 – 40 °C <41 – 104 °F> (0m / 0ft – 2,286m / 7,500ft)
5 – 35 °C <41 – 95 °F> (over 2,286m / 7,500ft) (20% – 80% humidity, No Condensation)Multi-projection Use:5 – 35 °C <41 – 95 °F> (0m / 0ft – 2,286m / 7,500ft)
5 – 30 °C <41 – 86 °F> (over 2,286m / 7,500ft) (20% – 80% humidity, No Condensation)

Operating Altitude:

Operating Altitude:0 – 3,000 m <0 – 9,843 ft>

Start-Up Period:

Start-Up Period:About 8 seconds, Warm-up Period: 30 seconds

Cool Down Period:

Cool Down Period:Instant Off

Internal Speaker(s):

Sound Output:16W Mono

Dimension Excluding Feet (W x H x D):367 x 149 mm x 400

Type:Electrostatic FilterMaintenance Cycle^*4:5,000 hours (Power Consumption: Normal)
10,000 hours (Power Consumption: Eco)

Fan Noise (Normal / Eco / Eco2):35dB / 30dB / 29dB

Vertical/Horizontal:±3° / ±3°Quick Corner:Yes

Microphone Input:1

Connection To Computer:USB, Network

Dimension Excluding Protrusion (DxWxH):51 x 210 x 95 mmWeight:450g

Direct Power On / Off:Yes

Interactive Unit:

Functions:Hover, Right Click, Auto Adjust Pen Area
