NEC P627UL 6200 lumens Laser Projector

NEC P627UL 6200 lumens Laser Projector

Type LCD
Brightness [AL] 6200
Resolution 1920 x 1200
Light Source Laser
Light Source Life [h] 20000
Weight [kg] 9.7

Description

NEC P627UL 6200 lumens Laser Projector

Super silent yet brilliantly versatile

Innovation grounded in the true needs of the user results in the P627UL, a laser projector that is so silent it goes unnoticed yet for the 6,200 ANSI lumen image projection, perfectly visible in brightly lit spaces. A new standard in silent operation, 22dB in Eco mode is quieter than the ticking of a watch and is unsurpassed by any other installation projector.  With 4K@30Hz input processing, comprehensive connectivity and supporting WUXGA resolution, the future-proofed projector delivers an eye-pleasing visual experience.

Install and forget – requiring zero maintenance over its long 20,000 hour life, the completely sealed optical engine and laser light source means filter and lamp replacement is obsolete; paired with a minimal power consumption of just 318W in normal mode, the P627UL ensures low operational costs.

With optional WiFi and embedded MultiPresenter function for wireless presentation and screen sharing, this is the ideal meeting room and classroom tool, but also meets the needs of rental and staging companies and digital signage use cases.

Benefits

  • No filter service required – a completely sealed optical laser LCD engine allows a filter-free design. Brilliant colour brightness is maintained and servicing costs need no longer feature in your budget.
  • Low Noise Level – with 22dB, the silent technology will not disturb your meeting.
  • Future-proof input management – thanks to 4K@30 Hz input processing.
  • No lamp replacement – up to 20,000 h maintenance free operation possible due to Laser Light Source.
  • Risk Group 2 – because of the Risk Group 2 compliance, no prescribed safety precautions are necessary.
Projection Technology 3LCD Technology
Native Resolution
1920 x 1200 (WUXGA)
Aspect Ratio 16:10
Contrast Ratio 1 600000:1
Brightness 1 6200 ANSI Lumen (approx. 60% in Eco Mode)
Lamp Laser Light Source
Light Source Life [hrs] 20000 2
Lens F= 1.5–2.1, f= 17.2–27.7 mm
Lens shift H:±29, V:+60,-0
Keystone correction +/- 30° manual horizontal / +/- 30° manual vertical
Projection Factor 1.23 – 2 : 1
Projection Distance [m] 0.8 – 12.9
Screen Size (diagonal) [cm] / [inch] Maximum: 762 / 300″; Minimum: 76.2 / 30″
Zoom Manual; x1.6
Focus Adjustment Manual
Supported Resolutions
1920×1200 (Maximum resolution of analog input);3840 x 2160 (Maximum resolution of digital input);3840×2160 @ 30hz digital

CONNECTIVITY

RGB (analog) Input: 1 x Mini D-sub 15 pin
Digital Input: 1 x HDBaseT; 2 x HDMI™ supporting HDCP
Audio Input: 1 x 3.5 mm Stereo Mini Jack for Computer analog; 2 x HDMI audio
Output: 1 x 3.5 mm Stereo Mini Jack (variable)
Control Input: 1 x D-Sub 9 pin (RS-232) (male)
LAN 1 x RJ45; Optional WLAN
USB 1 x Type B (for Service); 1x Type A (USB 2.0 high speed) with 2.0A Power Supply; 1x Type A (W-LAN Dongle)
Video Signals NTSC 3.58; NTSC 4.43; PAL; PAL-M; PAL-N; PAL60; SECAM

REMOTE CONTROL

Remote Control Aspect Ratio; Audio Control; Auto Adjust; Eco Mode Control; Freeze-function; Help-function; ID set; Keystone Correction; Magnify-function; Page (up, down); Picture Adjust; Picture Mute; Power (On-OFF); Presentation and Mouse Control; Select (up, down, left, right); Source Select

ELECTRICAL

Power Supply 100-240 V AC; 50 – 60 Hz
Power Consumption [W] 318 (Normal) / 237 (Eco) / 1.6 (Network Stand-by) / 0.3 (Stand-by)

MECHANICAL

Dimensions (W x H x D) [mm] 480 x 122 x 407 (without lens and feet)
Weight [kg] 9.7
Fan Noise [dB (A)] 22 / 27 (Eco / Normal)
Colour Versions White

ENVIRONMENTAL CONDITIONS

Operating Temperature [°C] 5 to 40
Operating Humidity [%] 20 to 80
Storage Temperature [°C] -10 to 50
Storage Humidity [%] 20 to 80

ERGONOMICS

Safety and Ergonomics CE; EAC; ErP; RoHS; TUEV Type Approved; TüV GS
Speakers [W] 1 x 20 (mono)

ADDITIONAL FEATURES

Special Characteristics Auto Power ON/OFF; Carbon Savings Meter; Constant Brightness Mode; Control ID Function; DICOM simulation; Direct Power-Off Function; Free Tilt; HDBaseT; Help Function; HTTP Browser Control; Kensington security slot; Keypad Lock; Light Source Adjustment; Magnify; Mouse Control with USB Display; MultiPresenter Function; NaViSet Administrator 2; Optional User Logo; OSD with 30 languages; Password Security System; Plug&Play W-LAN Option; Portrait Setting; Quick Start; Source Select with Beep Function; Test Pattern; Unique Power Saving Functions; USB Viewer; Virtual Remote for direct PC control

GREEN FEATURES

Ecological Materials Downloadable manuals; ECO packaging
Ecological Standards ErP compliant; RoHs compliant

WARRANTY

Projectors 3 years pan-European service
Light Source 3 years or 10000h (whatever comes first)

SHIPPING CONTENT

Shipping Contents 2x AAA Batteries; IR Remote Control (477E); Lens Cap; Power Cord (1.8 m); Projector; Quick Setup Guide; Security Sticker; Users Manual; Utility software
