AOC AG493UCX2 49″ 165Hz DQHD Curved Gaming Monitor
Ask for more info
AOC AG493UCX2 49″ 165Hz DQHD Curved Gaming Monitor
Screen size (inch)
48.8
Panel resolution
5120×1440
Refresh rate
165 Hz
Response time MPRT
1 ms
Sync technology (VRR)
Freesync Premium Pro
Curvature Radius
1800R
USB-C connectivity
USB-C 3.2 x 1 (DP alt mode, upstream, power delivery up to 65 W)
HDR (High Dynamic Range)
Vesa Certified DisplayHDR™ 400
Description
AOC AG493UCX2 49″ 165Hz DQHD Curved Gaming Monitor
Double the in-game immersion with the curved AG493UCX2: thanks to the vast screen space of 49″ (32:9) and a stunning Dual-QHD 5k resolution, you face a razor-sharp image whichever way you look. A gushing refresh rate of 165Hz and FreeSync Premium Pro ensure the smoothest images for even more realism.
49“ ultra-wide
With a size of 49”, ultra-wide displays provide double more screen space compared to regular monitors. The extra size makes for more efficient use of space and allows for an unprecedented 32:9 ratio.
1800R Curved
Curved design wraps around you putting you at the center of the action and provides an immersive gaming experience.
1ms MPRT – Moving Picture Response Time
MPRT is an acronym for moving picture response time. MPRT technology disables and enables your monitor backlight during picture changes. Through the reduced time a frame is shown on the monitor, “ghosting” and “blurring” effects are reduced, resulting in a smoother, more “fluid” feeling gaming experience.
165Hz Refresh Rate
A 165Hz refresh rate, well over twice the industry standard of 60Hz, makes games run smooth as silk. Realize the potential in your graphics card. Forget screen tearing and forget motion blur. Feel your reflexes become one with the action. Never look back.
USB-C
Simplify the connections with one cable only. The USB-C connection provides DisplayPort Alternate Mode for transferring high-resolution video signals from a notebook to the monitor while simultaneously charging the notebook’s battery from the monitor with USB power delivery. Additionally, the USB 3.1 ensures lightning-fast data transmission, so even transferring a 4K movie can be done in less than one minute.
KVM
Share one single keyboard, mouse and monitor between multiple computers with KVM switch hardware.
AOC Game Color and Shadow control
Bring the battle out of the shadows with AOC Shadow Control and AOC Game Color! Adjust grey levels for better picture detail and brighten dark areas or sink them back into blackness on the fly, without affecting the rest of the display.
Display information
Screen size (inch) 48.8
Screen size (cm) 124
Flat / Curved Curved
Curvature Radius 1800R
Display viewing Area (HxW) in mm
1193.472(H) x 335.664 (V)
Display hardness 3H
Panel treatment Antiglare (AG)
Pixel Pitch 0.2331
Pixels per Inch 109
Panel resolution 5120×1440
Resolution name DQHD
Aspect ratio 32:9
Panel type VA
Brightness in nits 400
Backlight type WLED
Refresh rate 165 Hz
Response time GtG 4 ms
Response time MPRT 1 ms
Static contrast ratio 3000:1
Dynamic contrast ratio 80M:1
Viewing angle (CR10) 178/178
Display colours 16.7 Million
Video Features
Sync technology (VRR)
Freesync Premium Pro
G-Sync compatible ✓
Sync range
48-165
Digital signal frequency
Horizontal： 30k~200kHz (HDMI) 30k~250kHz (DP,USB C) Vertical： 48~75Hz (HDMI) 48~120Hz (USB C) 48~165Hz (DP)
HDR (High Dynamic Range)
Vesa Certified DisplayHDR™ 400
Colour space (sRGB) CIE 1931 % 122
Colour space (DCI-P3) CIE 1976 % 91
Colour space (Adobe RGB) CIE 1976 % 98
Colour space (NTSC) CIE 1976 % 100
Flicker-Free ✓
Blue Light Technology
Low Blue Light
Multiview (PbP, PiP) PbP
KVM ✓
Cabinet information
Bezel type (front)
3-sided frameless
Bezel Colour (front)
Black
Bezel finishing (front)
Texture
Cabinet colour (backside)
Black
Cabinet finishing (backside)
Texture
Speakers ✓
Speaker power 5 W x 2
Kensington Lock ✓
Vesa wallmount
100×100
Ergonomic information
Tilt
3.5° ±1.5° ~ 13.5° ±1.5°
Height adjust (mm)
100mm
Swivel
15.5° ±1.5° ~ 15.5° ±1.5
Gaming Features
Game mode
RTS, FPS, Racing, Gamer 1, Gamer 2, Off
Gaming convenience
G-menu
Sustainability
WEEE ✓
Power Consumption
Power supply External
Power source 100 – 240V 50/60Hz
Power consumption on (typical) in watts 68
Power consumption standby in watts 0.5
Power consumption off in watts 0.5
Connectivity information
HDMI
HDMI 2.0 x 3
Display Port
DisplayPort 1.4 x 1
USB-C connectivity
USB-C 3.2 x 1 (DP alt mode, upstream, power delivery up to 65 W)
USB Hub ✓
USB Hub speed
USB 3.1 (Gen 1)
USB downstream ports 3
USB fast charge port ✓
Audio Output
Headphone out (3.5mm)
Product Dimensions
Product dimensions incl. base (H x W x D)
1194.4X(467.6~567.6)X308.0 MM
Product dimensions excl. base (L x W x H)
1194.4X369.4X153.24 MM
Packaging dimensions (L x W x H)
1308W*553D*420H MM
Gross weight incl. package (in kg) 20.8
Net weight excl. package (in kg) 14.4
Regulatory Compliance
Microsoft WHQL ✓
What’s in the box
HDMI cable 1.8
Displayport cable 1.8
USB-C to C cable 1.8
Power adaptor ✓
Other
Remote control
Other information
EAN
4038986118422
OSD languages
English, French, German, Czech, Russian, Kroatian, Chinese (traditional), Chinese (simplified), Spanish, Portuguese, Italian, Dutch, Swedish, Finnish, Polish, Japanese, Ukranian, Turkish, Korean
